KEY FEATURES
- 34mm MAIN TUBE - Type III Hard Anodized 34mm One-Piece 6061-T6 Aluminum Tube
- 56mm OBJECTIVE LENS - Large Objective Lens for Enhanced Image Quality
- FIRST FOCAL PLANE - First Focal Plane Reticle for Long Range Precision at all distances
- ED PRIME GLASS - Highest Quality Extra-Low Dispersion (ED) Apochromatic Japanese Glass with 99.7% Light Transmission (per lens)
- 7 LAYER MULTI-COATING - Proprietary 7-Layer Glass Coating System provides it toughness, durability, and hydrophobic properties
- ARGON PURGED & SEALED - Dry Argon Purged and Fully Sealed Components for Any Environment
- MRAD TURRETS AND RETICLE - Milliradian Reticle and Turret Combination for Long Range Accuracy and Repeatability, Shot After Shot
- COMPETITION TURRETS - Stainless Steel Competition Turrets with Zero Stop, Positive Click and 2-Turn Indicator. Repeatability is guaranteed!
- CLR™ COMPETITION RETICLE - Our proprietary reticle is the result of 2 years of research and development, perfectly designed for long range shooting and PRS-style competition where quick transitions and an unobstructed top-half of the reticle is key
- FOCUS AT ALL DISTANCES - Generous Eye Relief and Eye Box, and Parallax Side Focus Adjustment from 15 yards to Infinity
- IP67 WATER AND DUSTPROOF - Certified IP67 Dustproof / Waterproof and Shockproof to 1200 G's
- PRECISION CONSTRUCTION - Precision Constructed and Hand-Assembled in a Certified Clean Room
- SIX SIGMA QUALITY - SIX SIGMA Quality Control System & 3-Step Pre-Shipping Inspection Guarantees that you get a ready-to-shoot riflescope the first time, every time!
- BEYOND MIL-SPEC - Our products meet and exceed MIL-SPEC standards and will satisfy even the most stringent requirements of all civilian, agency, and military users
- DESIGNED BY PROFESSIONALS - Our team is comprised of professionally designated Project Managers, optical engineers, competitive shooters, veterans and LEO's
TECHNICAL SPECIFICATIONS
- Equipped with our exclusive 15 MRAD-per-turn stainless steel Competition Turrets with Zero-Stop and Pop-Up 2-Turn Indicator
- Proprietary glass-etched Apex CLR™ (Competition Long Range) reticle
- 6 Levels of illumination (Red) on the Main Stadia With an “OFF” position between each setting
- The first-in-industry see-through integrated & removable throw lever
- 0.1 MIL windage and elevation adjustment per Click
- 15 MILs per turn on the elevation turret
- Fast-Focus Eyepiece (+3/-2)
- Designed for and tested in the rugged terrain of the Canadian Rockies, the frozen tundra, the wet rainforest, the dry and dusty badlands throughout Southern Alberta, Saskatchewan and British Columbia
- Designed and Tested in Canada, Made in Japan
TECHNICAL INFORMATION
- Tube Diameter - 34mm
- Objective Lens - 56mm
- Magnification - 4-32x
- FOV @ 100y - 29.9ft-3.73ft
- Eye Relief - 3.54" (90mm)
- Exit Pupil - 8mm-1.6mm
- Parallax Range - 15y-Infinity
- Glass Type - ED
- Light Tx. Rate - 99.7%
- Focal Plane - First (FFP)
- Reticle - CLR
- Reticle Type - Glass Etched
- Elev. Adjustment - 32 MIL
- Wind. Adjustment - 20 MIL
- MILs/Rotation - 15E / 10W
- Turret Rotation - CCW
- Illumination Color - Red
- Illumin. Levels - 6 w/ On-Off
- Reticle Type - Glass Etched
- Length - 15" (381mm)
- Weight - 37oz (1049g)
- Mounting Length - 7.4" (189mm)
